Ashland Water Group SPP50V 1/2 Hp Aluminum Sump Pump

Product Description

The ASHLAND WATER GROUP SPP50V is a 1/2 HP anodized aluminum sump pump built for residential and light commercial basement water removal. It delivers 4080 gallons per hour and features a solids-handling vortex thermoplastic impeller that keeps the unit moving water even when fine debris is present. The motor includes built-in overload protection to guard against burnout during extended run cycles. A vertical float switch controls automatic operation without requiring manual intervention. Licensed plumbers and experienced service techs are the typical installers for this class of pump.

The SPP50V is designed for sump basins measuring at least 11 inches in diameter and 24 inches in depth. It fits standard residential sump pit configurations found in crawl spaces and basements where groundwater intrusion or foundation drainage is a recurring concern. The anodized aluminum construction holds up in wet, corrosive pit environments better than bare steel alternatives. This unit is a practical choice wherever reliable automatic water evacuation is needed in a confined basin footprint.

Key Features

• 1/2 HP motor rated for 4080 GPH flow capacity
• Anodized aluminum housing resists corrosion in wet pit environments
• Built-in overload motor protection prevents burnout during high-demand cycles
• Vertical float switch for automatic on/off operation
• Solids-handling vortex impeller made from thermoplastic for debris tolerance
• Fits basins 11 inches in diameter by 24 inches in depth minimum

Compatibility

Designed as an OEM-style replacement or direct-install sump pump for residential and light commercial sump pit applications requiring a 1/2 HP vertical-switch unit in a standard basin configuration.

Installation Notes

Installation should be performed by a licensed plumber in accordance with applicable local plumbing codes and IPC guidelines. Disconnect power at the circuit breaker before handling the pump or any wiring connections. Verify basin diameter and depth meet the minimum 11-inch by 24-inch requirement before lowering the unit into the pit. Ensure the discharge line is properly sized and the check valve is installed to prevent backflow after pump shutdown.

Technical Specifications

• Motor Power: 1/2 HP
• Flow Rate: 4080 GPH
• Minimum Basin Diameter: 11 inches
• Minimum Basin Depth: 24 inches
• Switch Type: Vertical
• Impeller Type: Solids Handling Vortex, Thermoplastic
• Housing Material: Anodized Aluminum and Thermoplastic
• Motor Protection: Built-in Overload
• Weight: 10 pounds

Standard Information

• Brand: ASHLAND WATER GROUP
• Manufacturer Part Number: SPP50V
