Ashcroft 82115XLL Pressure Gauge 2.5 in 0-5000 Psi Ss

Product Description

The ASHCROFT 82115XLL is an analog pressure gauge designed for industrial and mechanical systems requiring accurate pressure measurement across a wide range. It features a 2.5-inch dial with a 0 to 5000 psi range and delivers 1 percent of scale accuracy. The stainless steel case and stainless steel wetted parts make it suitable for demanding environments where corrosion resistance is critical. The center back mount configuration with a 1/4-inch threaded connection allows for clean panel or bulkhead installations. This gauge is dry (no liquid fill) and is typically installed by licensed plumbers, HVAC technicians, pipefitters, or industrial maintenance professionals.

The 82115XLL is suited for high-pressure applications in industrial, commercial, and mechanical systems. Its stainless steel construction makes it a strong fit for corrosive media or washdown environments. The center back mount orientation is common in panel-mounted gauge installations where the piping approach is from behind the mounting surface. Typical install scenarios include hydraulic lines, compressed gas systems, boiler rooms, and process piping where a full-scale range up to 5000 psi is required.

Key Features

• 0 to 5000 psi pressure range for high-pressure system monitoring
• 1 percent of scale accuracy for reliable readings
• 2.5-inch analog dial for easy at-a-glance readability
• Stainless steel case resists corrosion in harsh environments
• Stainless steel wetted parts compatible with a wide range of media
• Dry gauge (no liquid fill) for standard mechanical installations
• Center back mount with 1/4-inch thread for clean panel installations

Compatibility

Designed as an OEM-style replacement or direct-install pressure gauge for industrial, commercial, and mechanical piping systems requiring a center back mount, 1/4-inch threaded connection, and a 0 to 5000 psi range.

Installation Notes

Installation is typically performed by a licensed plumber, pipefitter, or qualified mechanical technician. Depressurize and isolate the system completely before removing an existing gauge or installing this unit. Apply appropriate thread sealant to the 1/4-inch male threads per the fitting manufacturer guidelines and applicable IPC or IFGC standards. Do not overtighten the threaded connection, as this can damage the gauge socket or the mating port.
