Ashcroft 662876752065 Digital Pressure Gauge 0-200 Psi

Product Description

The ASHCROFT 662876752065 is a digital pressure gauge designed for accurate real-time pressure monitoring in fluid and gas systems. It features a 2.5-inch digital display housed in a black plastic case, with stainless steel wetted parts that resist corrosion in demanding service environments. The gauge reads from 0 to 200 psi with 0.5% of scale accuracy, making it suitable for applications where precision matters. A 1/4-inch NPT lower-mount connection allows direct installation into threaded ports on equipment, piping, or manifolds. Licensed HVAC technicians, plumbers, and mechanical contractors are the typical installers for this type of instrument.

This gauge is suited for residential and light commercial mechanical systems where digital readout is preferred over analog. The IP67 ingress protection rating makes it appropriate for use in environments where moisture exposure is a concern. It carries CE, CRN, UL 61010, and cUL certifications, supporting use in both U.S. and Canadian installations. The polycarbonate lens protects the digital display from impact and environmental debris. Typical applications include boiler systems, compressed air lines, water supply systems, and refrigeration manifolds where an accurate, easy-to-read pressure indication is required.

Key Features

• Digital display with 0.5% of scale accuracy across the full 0 to 200 psi range
• 2.5-inch dial diameter for clear readability in tight installation spaces
• Stainless steel wetted parts for corrosion resistance in fluid and gas service
• IP67-rated enclosure resists dust ingress and temporary water immersion
• 1/4-inch NPT lower-mount connection for direct in-line installation
• Certified to CE, CRN, UL 61010, and cUL standards for broad code compliance

Compatibility

Designed as a direct-mount digital pressure gauge for systems with a 1/4-inch NPT lower-mount port operating within the 0 to 200 psi range and a working temperature between -4 degrees F and 140 degrees F.

Installation Notes

Installation is typically performed by a licensed plumber, HVAC technician, or mechanical contractor. Shut off the system and relieve all pressure before installing or removing the gauge. Apply thread sealant appropriate for the service medium to the NPT threads and hand-tighten before using a wrench for final seating. Do not exceed the rated pressure or temperature limits of the gauge during operation.
