Product Description
The Ashcroft 631008SL02L160 is a stainless steel liquid pressure gauge designed for measuring pressure in various applications. It features a lower mount design and a face diameter of sixty-three millimeters. This gauge has a pressure range from zero to one hundred sixty PSI, making it suitable for many industrial tasks.
- Liquid-filled for stability and accurate readings
- Constructed from stainless steel for durability
- Lower mount with one-fourth inch NPT connection
Product Highlights
This gauge is built to last with its all-welded stainless steel case that ensures longevity. The Powerflex movement enhances resistance to shock and vibration, which is ideal for tough environments. The True Zero pointer allows for accurate zero reading without a stop pin masking the measurement.
Product Information
Standard Information
-
Brand: Ashcroft
-
MPN: 631008SL02L160
Technical Specifications
-
Gauge Pressure Range: 0 to 160 psi
-
Gauge Function: Pressure Gauge
-
Socket Material: Stainless Steel
-
Tube Material: Stainless Steel
-
Temperature Range [Min]: 20 °F
-
Face Diameter: 63 mm
-
Gauge Type: Liquid
-
NPT Male: 1/4 in
-
Pressure Range [Max]: 160 psi
-
Mounting Style: Lower Mount
-
Pressure Range [Min]: 0 psi
-
Temperature Range [Max]: 150 °F
-
Case Material: Stainless Steel
-
Weight: 0.4 LB
-
EAN or UPC: 759426951938
