Ashcroft 631008SL02L100 Type 1008SL Stainless Steel-Case Gauge

Product Description

The Ashcroft 631008SL02L100 is a liquid pressure gauge with a stainless steel case. This gauge features a lower mounting style with a face diameter of sixty-three millimeters. It measures pressure from zero to one hundred PSI.

• All stainless, all-welded design
• Powerflex movement for shock resistance
• True Zero pointer indication

Product Highlights

This product can be used in various applications including HVAC systems, plumbing, and industrial equipment.

Product Information

Standard Information

• Brand: Ashcroft
• MPN: 631008SL02L100

Technical Specifications

• Face Diameter: 63 mm
• Socket Material: Stainless Steel
• Temperature Range [Max]: 150 °F
• Pressure Range [Min]: 0 psi
• Pressure Range [Max]: 100 psi
• Tube Material: Stainless Steel
• Gauge Function: Pressure Gauge
• Gauge Type: Liquid
• Mounting Style: Lower Mount
• Case Material: Stainless Steel
• NPT Male: 1/4 in
• Temperature Range [Min]: 20 °F
• Gauge Pressure Range: 0 to 100 psi
• Weight: 0.4 LB
• EAN or UPC: 759426951921
