Ashcroft 631008AL02L30 Type 1008AL Grade B Stainless Steel-Case Gauge

Product Description

The Ashcroft 631008AL02L30 is a Type 1008AL Grade B stainless steel case gauge. It is designed for measuring liquid pressure in various applications.

• Face Diameter: 63 mm
• Pressure Range: 0 to 30 psi
• Mounting: Lower Mount with 1/4 inch NPT

Product Highlights

This gauge features soldered brass socket and bronze tube design for durability. The corrosion-resistant stainless steel case ensures longevity. It includes a two-year warranty for peace of mind.

Product Information

Standard Information

• Brand: Ashcroft
• MPN: 631008AL02L30
• Gauge Function: Pressure Gauge
• Gauge Type: Liquid

Technical Specifications

• Case Material: Stainless Steel
• Mounting Style: Lower Mount
• Temperature Range [Min]: 20 °F
• Temperature Range [Max]: 150 °F
• Tube Material: Bronze
• Socket Material: Brass
• Weight: 0.4 LB
• Pressure Range [Min]: 0 psi
• Pressure Range [Max]: 30 psi
• Gauge Pressure Range: 0 to 30 psi
• EAN or UPC: 662876003501
