Ashcroft 251490A02L60IW Series 1490 Low Pressure Diaphragm Gauge 0-60 inH2O

Product Description

The Ashcroft 251490A02L60IW is a low pressure diaphragm gauge designed for precise measurement in various applications. This gauge measures pressure from zero to sixty inches of water column (inH2O). Ideal for environments where gases that are non-corrosive to beryllium copper and brass are present.

• 2 1/2 inch face
• Lower mount for easy installation
• Glass filled polysulfone case

Product Highlights

The gauge features a reliable beryllium copper diaphragm and is suitable for both positive and negative pressure applications.

Product Information

Standard Information

• Brand: Ashcroft
• MPN: 251490A02L60IW

Technical Specifications

• Pressure Range [Min]: 0 inH2O
• Gauge Function: Pressure Gauge
• Gauge Pressure Range: 0 to 60 inH2O
• Pressure Range [Max]: 60 inH2O
• Face Diameter: 2 1/2 inches
• Mounting Style: Lower Mount
• Case Material: Glass Filled Polysulfone
• NPT Male: 1/4 inches
• Gauge Type: Diaphragm
• Socket Material: Brass
• Weight: 0.4 LB
• EAN or UPC: 759426954502
