ASCO WT8551A001MSDC24/DCD Solenoid Valve - Female, 24 V dc, 4-Way, 2-Position, Normally Closed

Product Description

The ASCO WT8551A001MSDC24/DCD is a solenoid valve designed for reliable operation in pneumatic systems. This valve operates on a 24 volt direct current supply with a four-way, two-position configuration. It is classified as normally closed, ensuring that flow is stopped when not energized.

• Operating pressure range: 30 to 150 psi.
• Compatible with air as the fluid type.
• Constructed with an aluminum body and nitrile seal material.

Product Highlights

This valve is suitable for various pneumatic applications, ensuring efficient control of compressed air flows.

Product Information

Standard Information

• Product Name: Solenoid Valve - Female, 24 V dc, 4-Way, 2-Position, Normally Closed
• Brand: ASCO

Technical Specifications

• MPN: WT8551A001MSDC24/DCD
• Body Material: Aluminum
• Seal Material: Nitrile
• Overall Width: 45 mm
• Overall Height: 33 mm
• Overall Length: 192 mm
• Orifice Diameter: 1/4 in
• Port 1 Size/Type: 1/4 NPT
• Number Of Solenoids: 1
• Solenoid Supply Voltage: 24 V dc
• Operating Temperature Range: Maximum of 140 °F
• Operating Pressure Range: +30 to +150 psi
• Flow Coefficient Cv Flow Factor Kv: 0.86 Cv
• Maximum Operating Pressure: +150 psi
• Minimum Operating Pressure: 30 psi
• Solenoid Power Consumption: 6.3 W
• Solenoid Electrical Entry: DIN Terminal
• Valve Functionality: 4-Way, 2-Position, Normally Closed
• Compatible Fluid Type: Air
• Additional Details: Return Spring
• Standards Met: UL, CSA
