Asco H118AJ142A209 2in. Gas Shutoff Valve

Asco H118AJ142A209 2in. Gas Shutoff Valve

Description:
The normally closed H118 is a combination Hydramotor actuator and safety shutoff/control gas valve. It is used for commercial and industrial burners in applications such as furnaces, dryers, dehydrators, conversion burners and heaters. The cast iron, globe-type valve body features a soft synthetic seat and integral heavy-duty return spring for tight and certain closure in one second or less upon current interruption.

Specifications:
Pipe size: 2
Flow factor CV: 67
Gas capacity: 3300
Operating Pressure Min: 0
Operating Pressure Max: 15psi
Max. Flued Temp: 150F
