Asc Engineered Solutions 8700129300 Black Iron Hex Bushing

Product Description

The ASC Engineered Solutions 8700129300 is a malleable black iron hex bushing designed to reduce a 1-inch male-threaded pipe connection down to a 1/2-inch female thread. This concentric reducing bushing is used in ferrous piping systems where a threaded pipe or fitting must be stepped down to a smaller nominal pipe size. The hexagonal outer profile allows wrench engagement for proper thread engagement torque. Suitable for gas, steam, water, and air service applications in light commercial and residential piping systems. Licensed plumbers and pipefitters are the primary installers of this fitting.

This bushing is appropriate for use in residential and light commercial plumbing, HVAC hydronic, and gas-distribution piping systems where a 1-inch to 1/2-inch threaded reduction is required. The malleable iron construction handles the mechanical stress of threaded assembly in service conditions typical of low-pressure piping. Sold individually.

Key Features

• Malleable black iron construction for durability in ferrous piping systems
• 1-inch male thread to 1/2-inch female thread hex reducing bushing
• Hexagonal outer body provides flat wrench engagement surfaces
• Meets Federal Specification WW-P-471-B for ferrous plugs, bushings, and locknuts
• Dimensionally compliant with ANSI B-16.14 and threaded to ANSI B-2.1

Compatibility

Designed as an OEM-style replacement fitting for standard NPT-threaded malleable iron piping assemblies where a 1-inch to 1/2-inch hex bushing reduction is required.

Installation Notes

Installation should be performed by a licensed plumber or pipefitter following applicable local codes and IFGC or IPC requirements for the intended service. Shut off and depressurize the piping system before disassembly or installation. Apply listed thread sealant or PTFE tape to the male threads before assembly. Do not over-tighten; hand-tighten and then advance with a pipe wrench to achieve a leak-free joint.

Technical Specifications

• Material: Malleable Black Iron
• Connection Type: 1 inch Male NPT x 1/2 inch Female NPT
• Body Style: Hexagon (Hex Bushing)
• Standards: Fed. Spec. WW-P-471-B, ANSI B-16.14, ANSI B-2.1
• Weight: 0.102 pounds
• Sold As: Each

Standard Information

• Brand: ASC Engineered Solutions
• Manufacturer Part Number: 8700129300
