Asc Engineered Solutions 560500225 Split Ring Hanger 1-1/4 in

Product Description

The ASC Engineered Solutions 560500225 is a galvanized carbon steel split ring hanger designed to support pipe in suspended piping systems. The hanger features a split ring design that allows installers to snap the fitting onto pipe without threading the pipe through the ring, speeding up installation in overhead applications. It is sized for 1-1/4 inch pipe and accepts a 3/8 inch threaded hanger rod. The galvanized finish provides corrosion resistance in damp or moderately corrosive environments. At 0.22 pounds per unit, it is lightweight and easy to handle in volume installations. Plumbers and mechanical contractors use this type of hanger in residential and commercial plumbing, HVAC piping, and general mechanical systems.

This split ring hanger is suited for use in suspended pipe support applications where pipe must be hung from structural members, beams, or concrete ceilings using threaded rod. It is commonly installed in mechanical rooms, commercial buildings, and residential construction wherever 1-1/4 inch pipe runs require consistent, secure overhead support. The 3/8 inch rod size is a standard specification for light- to medium-load pipe support applications in both new construction and retrofit projects.

Key Features

• Split ring design allows fast installation without threading pipe through the hanger
• Sized for 1-1/4 inch pipe with 3/8 inch threaded rod connection
• Galvanized carbon steel construction for corrosion resistance
• Lightweight at 0.22 pounds per unit for easy handling in volume work
• Suitable for suspended pipe support in plumbing and mechanical piping systems

Compatibility

Designed as an OEM-style replacement and standard-fit split ring hanger for 1-1/4 inch pipe suspended on 3/8 inch threaded rod in residential and commercial plumbing and mechanical piping systems.

Installation Notes

Installation is typically performed by licensed plumbers or mechanical contractors in accordance with applicable plumbing codes such as the IPC and local jurisdictional requirements. Shut off the pipe system and relieve pressure before making any piping connections in the vicinity. Ensure the threaded rod and structural attachment point are rated for the combined load of the pipe, contents, and hanger assembly. Do not overtighten the split ring closure, as this can deform the fitting and reduce holding strength.

Technical Specifications

• Size: 1-1/4 inches
• Rod Size: 3/8 inches
• Material: Carbon Steel
• Finish: Galvanized
• Type: Split Ring Hanger
• Weight: 0.22 pounds per unit

Standard Information

• Brand: ASC Engineered Solutions
• Manufacturer Part Number: 560500225
