Asc Engineered Solutions 390202109 Flange Adapter 6x11

Product Description

The ASC Engineered Solutions 390202109 is a grooved end flange adapter designed to connect grooved-end piping systems to flanged equipment or pipe ends. This fitting serves as a transition point between grooved mechanical coupling systems and standard flange connections, allowing installers to integrate grooved piping infrastructure with flanged pumps, valves, and equipment. It is sized at 6 inches by 11 inches, making it suited for medium to large commercial and industrial piping applications. Licensed pipefitters and mechanical contractors typically install this fitting as part of hydronic, fire protection, or industrial fluid-handling systems.

This grooved end flange adapter is used in commercial and industrial mechanical systems where grooved piping must interface with flanged components. Typical applications include hydronic heating and cooling systems, fire suppression distribution mains, and industrial process piping. The 6-inch grooved end dimension accommodates standard 6-inch grooved pipe, while the flange face provides a bolted connection to matching flanged equipment or valving.

Key Features

• Transitions grooved-end pipe to a flanged connection in a single fitting
• 6-inch grooved end accommodates standard 6-inch grooved pipe
• 11-inch overall dimension suits medium to large commercial piping installations
• Compatible with standard mechanical grooved coupling systems
• Reduces the need for additional adapters or spool pieces at flange-to-groove transitions

Compatibility

Designed as an OEM-style grooved end flange adapter for use in grooved mechanical piping systems requiring a transition to flanged connections on 6-inch pipe.

Installation Notes

Installation should be performed by a licensed pipefitter or mechanical contractor in accordance with applicable plumbing and mechanical codes, including ASME and local authority requirements. Isolate and depressurize the piping system fully before removing or installing any fitting. Verify that the flange bolt pattern, pressure rating, and gasket material are compatible with the mating equipment before final assembly. Do not overtighten bolts unevenly; follow a cross-pattern sequence to ensure proper gasket seating.

Technical Specifications

• Pipe Size: 6 inches
• Overall Dimension: 6 inches x 11 inches
• Connection Type: Grooved end to flange

Standard Information

• Brand: ASC Engineered Solutions
• Manufacturer Part Number: 390202109
