Asc Engineered Solutions 390117125 Grooved 45 Elbow 3 in

Product Description

The ASC Engineered Solutions 390117125 is a galvanized grooved 45-degree elbow fitting designed for use in grooved piping systems. Built from ductile iron with a galvanized finish, this 3-inch elbow provides a reliable directional change in pressurized piping runs. It is compatible with standard grooved coupling systems and is sized for 3-inch pipe. Mechanical contractors, pipefitters, and plumbing professionals install this type of fitting where a 45-degree directional change is required without welding or threading. The galvanized coating helps resist corrosion in wet or exposed environments.

This fitting is suited for commercial and industrial piping applications including HVAC hydronic systems, fire protection, and general mechanical piping. The grooved end design allows for fast assembly using a standard grooved mechanical coupling, reducing installation time compared to flanged or threaded alternatives. It is appropriate for above-ground piping installations where grooved-style connections are specified by design.

Key Features

• 45-degree elbow geometry for direction changes in grooved piping systems
• Ductile iron construction for strength and durability under pressure
• Galvanized finish provides corrosion resistance in wet or exposed environments
• 3-inch fitting size for standard grooved pipe connections
• Compatible with standard grooved mechanical couplings for tool-based assembly

Compatibility

Designed as an OEM-style grooved fitting for use with standard 3-inch grooved mechanical coupling systems in commercial and industrial piping applications.

Installation Notes

Installation should be performed by a licensed pipefitter or mechanical contractor familiar with grooved piping systems. Depressurize and drain the piping system completely before installing or removing any grooved fittings. Use the appropriate grooved coupling and follow the coupling manufacturer's torque and assembly procedures. Verify that pipe ends are properly grooved to the correct specification before joining.

Technical Specifications

• Fitting Size: 3 inches
• Elbow Degree: 45 degrees
• Fitting Material: Ductile Iron
• Finish: Galvanized
• Item Weight: 2.80 pounds

Standard Information

• Brand: ASC Engineered Solutions
• Manufacturer Part Number: 390117125
