Asc Engineered Solutions 390116564 Grooved 90 Elbow 3 in

Product Description

The ASC Engineered Solutions 390116564 is a galvanized grooved 90-degree elbow fitting designed for use in grooved piping systems. Manufactured from ductile iron with a galvanized finish, this 3-inch elbow provides a 90-degree change of direction in mechanical-joint pipe assemblies. At 3.75 pounds, it is built for the physical demands of commercial and industrial piping installations. Licensed pipefitters and mechanical contractors install this fitting as part of a grooved coupling system, eliminating the need for welding or threading at the joint.

This elbow is suited for fire protection, HVAC hydronic, and general industrial piping applications where grooved mechanical joining is specified. The 3-inch size fits standard grooved pipe of the same nominal diameter. It is commonly used in new construction and retrofit projects in commercial buildings where grooved piping systems are the preferred or code-required joining method.

Key Features

• 90-degree change of direction for grooved piping systems
• 3-inch nominal fitting size for standard grooved pipe
• Ductile iron construction for high strength and impact resistance
• Galvanized finish for corrosion protection in wet or humid environments
• Mechanical grooved joint design eliminates welding or threading at connection points

Compatibility

Designed as an OEM-style replacement and standard fitment for 3-inch grooved piping systems using mechanical coupling assemblies in commercial HVAC, fire protection, and industrial piping applications.

Installation Notes

Installation should be performed by a licensed pipefitter or mechanical contractor familiar with grooved piping systems and applicable codes. Depressurize and drain the piping system before removing any existing fittings or couplings. Verify that pipe ends are cut square and that grooves meet the dimensional requirements of the coupling manufacturer before assembling. Follow all applicable plumbing and mechanical codes, including NFPA 13 where fire protection systems are involved.

Technical Specifications

• Fitting Size: 3 inches
• Elbow Degree: 90
• Fitting Material: Ductile Iron
• Finish: Galvanized
• Weight: 3.75 pounds

Standard Information

• Brand: ASC Engineered Solutions
• Manufacturer Part Number: 390116564
