Asc Engineered Solutions 390014264 Grooved 90 Elbow 3 in

Product Description

The ASC Engineered Solutions 390014264 is a grooved 90-degree elbow fitting designed for use in piped mechanical systems requiring a right-angle change of direction. Manufactured from ductile iron with a painted finish, this fitting connects to grooved-end pipe using standard mechanical couplings. It is sized for 3-inch pipe and weighs 3.75 pounds. Licensed pipefitters and mechanical contractors install this type of fitting in commercial and industrial hydronic, fire protection, and process piping systems where grooved mechanical joining is specified.

This 90-degree grooved elbow is suited for both above-ground and accessible below-ceiling piping installations. Grooved fittings are widely used in commercial buildings, industrial facilities, and institutional projects where fast assembly, system flexibility, and ease of future maintenance are priorities. The painted ductile iron construction makes this fitting appropriate for interior dry applications where standard corrosion protection is acceptable.

Key Features

• 90-degree elbow provides a full right-angle direction change in grooved piping runs
• Ductile iron construction offers high strength and impact resistance compared to cast iron
• Painted exterior finish provides standard corrosion protection for interior applications
• 3-inch grooved end connections mate with standard mechanical couplings and grooved pipe
• Grooved joining system eliminates field welding and reduces installation labor

Compatibility

Designed as an OEM-style replacement or new-installation grooved pipe fitting for 3-inch grooved mechanical piping systems in commercial and industrial applications.

Installation Notes

Installation should be performed by a licensed pipefitter or mechanical contractor in accordance with applicable local mechanical codes. Depressurize and drain the piping system fully before removing or installing any grooved fittings or couplings. Inspect pipe-end grooves for proper depth and width before seating the coupling gasket. Follow the coupling manufacturer torque and gasket lubrication requirements to ensure a leak-free joint.

Technical Specifications

• Fitting Size: 3 inches
• Elbow Degree: 90 degrees
• Fitting Material: Ductile Iron
• Finish: Painted
• Item Weight: 3.75 pounds

Standard Information

• Brand: ASC Engineered Solutions
• Manufacturer Part Number: 390014264
