Asc Engineered Solutions 361124803 Reducing Tee 3000 Lb

Product Description

The ASC ENGINEERED SOLUTIONS 361124803 is a forged steel threaded reducing tee rated for 3000 lb pressure service. This fitting connects a 1-1/2 inch run pipe to a 1-1/4 inch branch outlet using full-thread engagement on all three ports. The compact forged construction provides the density and structural integrity required for high-pressure piping systems. It is installed by licensed plumbers and pipefitters in industrial, commercial, and mechanical piping applications where reducing branch connections are required at elevated pressures.

This reducing tee is suited for use in high-pressure steam, gas, oil, and water piping systems where a branch connection must transition to a smaller nominal pipe size. The 3000 lb pressure class makes it appropriate for demanding mechanical room and industrial process installations. The threaded end connections allow for tool-only installation without welding, making it a practical choice for retrofit and maintenance work in systems that require periodic disassembly.

Key Features

• Forged steel construction for high-pressure, high-integrity service
• 3000 lb pressure class rating for demanding piping applications
• Threaded end connections on all three ports for tool-only installation
• Reducing configuration transitions a 1-1/2 inch run to a 1-1/4 inch branch outlet
• Full-thread engagement provides secure, leak-resistant joints when properly sealed

Compatibility

Designed as an OEM-style replacement or new-installation threaded reducing tee for 3000 lb class forged steel piping systems using 1-1/2 inch and 1-1/4 inch NPT threaded pipe.

Installation Notes

Installation should be performed by a licensed plumber or pipefitter in accordance with applicable mechanical and plumbing codes. De-pressurize and isolate the piping system completely before removing or installing any threaded fitting. Apply appropriate thread sealant or PTFE tape to all male threads before assembly, and tighten to the fitting manufacturer's recommended engagement using pipe wrenches. Do not over-torque, as this can crack or distort forged fittings.

Technical Specifications

• Material: Forged Steel
• Fitting Size: 1-1/2 inches x 1-1/4 inches
• Pressure Class: 3000 lb
• Connection Type: Threaded Reducing
• Weight: 7.05 pounds

Standard Information

• Brand: ASC ENGINEERED SOLUTIONS
• Manufacturer Part Number: 361124803
