Asc Engineered Solutions 361124100 Forged Steel Reducing Tee

Product Description

The ASC Engineered Solutions 361124100 is a forged steel threaded reducing tee rated to a 3000 lb pressure class. It measures 1-1/4 inches on the run with a 1-inch branch outlet, making it the right choice when a piping run needs to step down to a smaller branch line under high-pressure service conditions. The forged steel construction provides the density and strength required for demanding industrial and commercial piping systems. Licensed plumbers and pipefitters install this fitting in threaded black iron or carbon steel pipe assemblies where mechanical integrity under pressure is critical.

This reducing tee is suited for high-pressure threaded piping systems found in commercial and industrial facilities, including steam, gas, oil, and hydraulic distribution lines. The 3000 lb pressure class designation makes it appropriate for applications requiring robust fittings beyond standard 150 lb or 300 lb service ratings. It is typically used in mechanical rooms, process piping, and utility distribution systems where reducing tee connections are needed to branch off at a smaller pipe size.

Key Features

• Forged steel construction for high strength and pressure resistance
• 3000 lb pressure class rating for demanding service conditions
• Threaded end connections for tool-based assembly without welding
• Reducing configuration: 1-1/4 inch run x 1 inch branch outlet
• Compatible with standard threaded black iron and carbon steel pipe systems

Compatibility

Designed as an OEM-style replacement or new-installation fitting for high-pressure threaded steel piping systems rated to 3000 lb class service.

Installation Notes

Installation should be performed by a licensed plumber or pipefitter in accordance with applicable mechanical and plumbing codes, including ASME B1.20.1 thread standards for NPT fittings. Depressurize and isolate the piping system completely before removing or installing any threaded fittings. Apply an appropriate thread sealant or PTFE tape rated for the service medium to all male threads before assembly. Do not over-torque threaded connections, as this can damage the fitting or the mating pipe threads.

Technical Specifications

• Fitting Material: Forged Steel
• Fitting Size: 1-1/4 inches x 1 inch
• Pressure Class: 3000 lb
• Connection Type: Threaded Reducing
• Item Weight: 3.50 pounds

Standard Information

• Brand: ASC Engineered Solutions
• Manufacturer Part Number: 361124100
