Asc Engineered Solutions 361109358 90 Deg Street Elbow 1/4 in

Product Description

The ASC Engineered Solutions 361109358 is a forged steel 90-degree street elbow with male threaded ends, rated for 3000 lb pressure class service. This fitting is designed for high-pressure piping systems where a directional change is required inline. The street elbow configuration features one male threaded end and one female threaded end, eliminating the need for an additional nipple in tight-run installations. Sized at 1/4 inch, it is a compact fitting suited for instrumentation lines, compressed air, hydraulic, and similar high-pressure applications. Weighing 0.23 pounds, the forged steel construction delivers the strength and durability required for demanding service conditions. Licensed plumbers and pipefitters are the typical installers for this type of fitting.

This 90-degree street elbow is used in residential and commercial piping installations where a directional change is needed at a threaded connection point. Its compact 1/4 inch size makes it well suited for instrument takeoffs, control line piping, and other small-bore high-pressure runs. The 3000 lb pressure class rating qualifies it for use in applications demanding robust threaded fittings under sustained or cyclic pressure loads.

Key Features

• Forged steel construction for high-pressure service durability
• 90-degree street elbow configuration with male and female threaded ends
• 3000 lb pressure class rating for demanding piping applications
• 1/4 inch fitting size for small-bore and instrumentation piping runs
• Lightweight at 0.23 pounds for easy handling in confined spaces

Compatibility

Designed as an OEM-style replacement or new-install threaded street elbow for 1/4 inch male threaded piping systems rated to 3000 lb pressure class service.

Installation Notes

Installation should be performed by a licensed plumber or pipefitter in accordance with applicable mechanical and plumbing codes. Isolate and depressurize the system fully before making or breaking any threaded connection. Apply an appropriate thread sealant or PTFE tape to male threads per the system fluid compatibility requirements. Do not over-torque threaded fittings; hand-tight plus wrench turns per standard practice is the accepted method for tapered pipe threads.

Technical Specifications

• Fitting Size: 1/4 inch
• Elbow Degree: 90 degrees
• Type: Street Elbow Male Threaded
• Pressure Class: 3000 lb
• Fitting Material: Forged Steel
• Item Weight: 0.23 pounds

Standard Information

• Brand: ASC Engineered Solutions
• Manufacturer Part Number: 361109358
