Asc Engineered Solutions 308011006 Reducing Flange 3 in

Product Description

The ASC Engineered Solutions 308011006 is a 3-inch black cast iron reducing flange rated at 125 lb class. It is designed to connect a 3-inch pipe to a larger mating surface, with a 13.5-inch outer diameter that accommodates standard bolt circle patterns at this pressure class. The black coating provides basic corrosion resistance for typical indoor piping installations. This flange is installed by licensed plumbers and pipefitters working on low-pressure water, drain, or general service piping systems where a reducing flange connection is required.

This reducing flange is suited for residential and light commercial piping applications operating within 125 lb class pressure ratings. It is commonly used where a 3-inch pipe branch must terminate or transition at a flanged connection point, including mechanical rooms, pump stations, and general process piping assemblies. Domestic manufacture supports traceability requirements on projects with Buy American or material documentation clauses.

Key Features

• 3-inch pipe size with 13.5-inch outer diameter for standard 125 lb flange bolt patterns
• 125 lb class pressure rating suitable for low-pressure piping service
• Cast iron construction provides durability in typical mechanical piping environments
• Black coating finish for corrosion resistance in interior applications
• Reducing flange design allows transition between pipe and larger flanged connections
• Domestically manufactured

Compatibility

Designed as an OEM-style replacement or new-installation fitting for 125 lb class cast iron flanged piping systems with a 3-inch pipe connection.

Installation Notes

Installation should be performed by a licensed plumber or pipefitter in accordance with applicable codes such as the International Plumbing Code. Isolate and depressurize the piping system and drain the line completely before removing or installing any flange fitting. Use appropriate gaskets and fasteners rated for 125 lb class service, and torque bolts evenly in a cross pattern following the gasket and flange manufacturer guidelines. Inspect the mating flange face for damage or debris before assembly.

Technical Specifications

• Fitting Size: 3 inches
• Outer Diameter: 13.5 inches
• Pressure Class: 125 lb
• Type: Reducing Flange
• Fitting Material: Cast Iron
• Coating: Black
• Weight: 40 pounds
• Country of Origin: Domestic

Standard Information

• Brand: ASC Engineered Solutions
• Manufacturer Part Number: 308011006
