Asc Engineered Solutions 1330026190 Fig BV835 Ball Valve 6 in

Product Description

The ASC ENGINEERED SOLUTIONS 1330026190 is a 6-inch nominal, 2-piece ductile iron ball valve in the FIG BV835 series, designed for efficient fluid control in grooved piping systems. It features a grooved end style for direct use with Gruvlok grooved couplings, a 304 stainless steel ball, and a carbon-filled TFE ball seat. The valve is rated to 800 psi and operates via a lever actuator with a padlockable handle. Inlet to outlet length measures 10.15 inches, and top to inlet center measures 8.68 inches. Licensed mechanical contractors and pipefitters install this valve in commercial and industrial piping applications.

The FIG BV835 is suited for commercial and industrial fluid control systems where grooved-end piping connections are specified. Its regular port, 2-piece construction supports high-pressure service across a range of liquid media. Flow is bidirectional, and the valve can be mounted in any orientation, giving installers flexibility in tight mechanical rooms or complex pipe runs. The ISO 5211 mounting pad allows field installation of pneumatic or electric power actuators when automated operation is required.

Key Features

• 800 psi pressure rating for demanding commercial and industrial service
• 304 stainless steel ball with carbon-filled TFE seat for durability and sealing performance
• Grooved end connections compatible with Gruvlok grooved couplings
• Lever operated with padlockable handle for lockout in open or closed position
• ISO 5211 mounting pad supports field-installed power actuators
• Bidirectional flow and any-orientation mounting for flexible installation
• Designed and tested in conformance with MSS SP-110 and MSS SP-72

Compatibility

Designed for use with Gruvlok grooved couplings in grooved-end piping systems. Conforms to MSS SP-110 and MSS SP-72 standards. ISO 5211 mounting pad accommodates compatible power actuators.

Installation Notes

Installation should be performed by a licensed pipefitter or mechanical contractor in accordance with applicable mechanical and plumbing codes. Depressurize and isolate the piping system fully before removing or installing the valve. Grooved ends require proper coupling installation per the coupling manufacturer specifications. When mounting a power actuator, verify actuator compatibility with the ISO 5211 pad pattern before installation.

Technical Specifications

• Series: FIG BV835
• Nominal Size: 6 inches
• End Style: Grooved
• Port Type: Regular Port
• Pressure Rating: 800 psi
• Actuator Type: Lever Operated
• Inlet to Outlet Length: 10.15 inches
• Top to Inlet Center: 8.68 inches
• Body Material: Ductile Iron
• Ball Material: 304 Stainless Steel
• Ball Seat Material: Carbon-Filled TFE
• Stem Material: Carbon Steel
• Stem Seal Material: PTFE
• Finish: Black Oxide
• Actuator Mounting Pad: ISO 5211
• Standards Compliance: MSS SP-110, MSS SP-72

Standard Information

• Brand: ASC ENGINEERED SOLUTIONS
• Manufacturer Part Number: 1330026190
