Asc Engineered Solutions 1330012210 Fig 619 Cts Grooved Copper Tee

Product Description

The ASC ENGINEERED SOLUTIONS 1330012210 is a FIG 619 CTS (Copper Tube Size) grooved tee fitting designed for use in grooved piping systems. Manufactured from copper with a 2-1/2 inch nominal size and a 2-5/8 inch OD, this tee provides a reliable branch connection in pressurized fluid systems. It is engineered to mate with compatible grooved couplings and adapters, making it a practical choice for mechanical contractors and pipefitters working on commercial or industrial hydronic, plumbing, or fire protection piping systems. The fitting meets ANSI/NSF 61, UL/ULC, and UPC listing requirements.

This fitting is suited for grooved copper piping installations in commercial and light industrial applications, including hydronic heating and cooling systems, domestic water distribution, and other fluid-handling systems where copper is the specified material. It is intended for use with compatible grooved couplings and transition hardware. Plumbers and mechanical contractors typically install this fitting as part of a fully grooved copper piping assembly. Compatible coupling and adapter families noted by the manufacturer include FIG 640 Pivot-Bolt Rigid Couplings, FIG 672 Rigid Couplings, FIG 616 Reducing Coupling, FIG 617 Transition Coupling, and FIG 61H/61 Flange Adapters.

Key Features

• 2-1/2 inch nominal grooved end tee with 2-5/8 inch OD for CTS copper pipe systems
• Copper construction provides corrosion resistance in water and fluid service
• Grooved end style allows fast, tool-accessible mechanical assembly without open flame
• Meets ANSI/NSF 61 for potable water contact applications
• UL/ULC Listed and UPC Listed for broad code acceptance
• Manufactured in the United States

Compatibility

Designed for use with FIG 640 Pivot-Bolt Rigid Couplings, FIG 672 Rigid Couplings, FIG 616 Reducing Coupling, FIG 617 Transition Coupling, and FIG 61H/61 Flange Adapters in grooved copper tube size piping assemblies.

Installation Notes

Installation of grooved copper fittings should be performed by a licensed plumber or mechanical contractor in accordance with applicable IPC and local plumbing codes. Shut off and depressurize the piping system fully before disassembly or fitting installation. Inspect the pipe end groove for proper dimensions and cleanliness before seating the coupling housing. Do not substitute non-rated couplings or exceed the pressure and temperature ratings listed by the coupling manufacturer.

Technical Specifications

• Nominal Size: 2-1/2 inches
• Outside Diameter (OD): 2-5/8 inches
• End Style: Grooved
• Material: Copper
• Series: FIG 619
• Weight: 3.8 pounds
• Standards and Approvals: ANSI/NSF 61, UL/ULC Listed, UPC Listed
• Country of Origin: US

Standard Information

• Brand: ASC ENGINEERED SOLUTIONS
• Manufacturer Part Number: 1330012210
