Asc Engineered Solutions 0309003200 3X7-1/2 Galv CI F&D Thrd Flng

Product Description

The ASC ENGINEERED SOLUTIONS 0309003200 is a companion flange with a thread connection. This flange, part of the FIG 1011 series, is made of galvanized cast iron and is domestic. It is 3 inches in nominal size with a 3/4 inch thickness and a 7-1/2 inch outside diameter. Suitable for plumbing, HVAC, industrial, and fire protection applications.

• Threaded companion flanges offer an economical way to convert the plain end of a pipe to a flanged connection
• ASME B16.1
• cULus Listed

Product Highlights

Threaded companion flange made of galvanized cast iron with 3 in nominal size.

Product Information

Standard Information

• Brand: ASC ENGINEERED SOLUTIONS
• Manufacturer Part Number: 0309003200

Technical Specifications

• Connection Type: Thread
• Domestic/Import: Domestic
• Finish: Galvanized
• Hub Diameter: 4-1/4 in
• Length Through Hub: 1-3/16 in
• Material: Cast Iron
• Nominal Size: 3 in
• Number of Bolt Holes: 4
• Outside Diameter: 7-1/2 in
• Pressure Class: 125 lb
• Pressure Rating: 200 psi
• Series: FIG 1011
• Temperature Rating: -20 to 150 deg F
• Thickness: 3/4 in
• Manufacturer: ASC Engineered Solutions
• Schedule: Standard
• Applicable Standards: ASME B16.1/B1.20.1, FM, UL (CANADA AND US)
• Application: Plumbing, Mechanical, HVAC, Industrial, Fire Protection, Mining, Oil, Gas
• Material Specification: ASTM A126/A153
• End Connection: Female Threaded
• Packaging Type: Bulk
• Model: 1011
• Dimensions: 7-1/2 in OD x 1-3/16 in L
