Asc 8700129250 Black Iron Hex Bushing 1 in X 3/8 in

Product Description

The ASC Engineered Solutions 8700129250 is a malleable black iron hexagon bushing used to reduce a 1-inch female threaded pipe opening to a 3/8-inch male threaded connection. Malleable iron construction provides the durability and thread integrity required for gas, air, and general plumbing piping systems. The hex profile allows a wrench to be applied directly for secure installation without slippage. This fitting is sold individually and is a standard item for plumbing contractors, pipefitters, and HVAC technicians working with threaded black iron piping systems.

This hex bushing is suited for residential and light commercial applications where a threaded reduction is needed in a black iron piping run. Typical install scenarios include gas supply lines, compressed air distribution, and general plumbing piping where a change in pipe diameter is required at a fitting or valve connection. The 1-inch female end threads onto the existing pipe or fitting, and the 3/8-inch male end accepts the downstream component.

Key Features

• Malleable black iron construction for strength and thread durability
• Hex body profile for wrench engagement during installation
• 1-inch female thread inlet, 3/8-inch male thread outlet
• Meets Fed. Spec. WW-P-471-B for ferrous plugs and bushings
• Dimensions per ANSI B-16.14, pipe threads per ANSI B-2.1
• Sold as a single unit (each)

Compatibility

Designed as a standard OEM-style threaded reduction fitting for black iron piping systems where a 1-inch to 3/8-inch NPT reduction is required.

Installation Notes

Installation should be performed by a licensed plumber or pipefitter following applicable local codes and IFGC requirements when used in gas service. Shut off and depressurize the piping system completely before removing or installing any threaded fittings. Apply an appropriate thread sealant or PTFE tape rated for the service fluid before assembly. Use a wrench on the hex body to achieve a proper make-up without overtightening.

Technical Specifications

• Material: Malleable Black Iron
• Inlet Thread Size: 1 inch female NPT
• Outlet Thread Size: 3/8 inch male NPT
• Body Style: Hexagon
• Weight: 0.15 pounds
• Standards: Fed. Spec. WW-P-471-B, ANSI B-16.14, ANSI B-2.1
• Unit of Measure: Each
• UPC: 00690291035715

Standard Information

• Brand: ASC Engineered Solutions
• Manufacturer Part Number: 8700129250
