Asc 8700127353 3/4 in 90 Deg Street Black Iron Elbow

Product Description

The ASC ENGINEERED SOLUTIONS 8700127353 is a 3/4-inch 90-degree street malleable black iron elbow, also known as a 1/4 bend. It features one male NPT thread and one female NPT thread, allowing it to connect directly to a pipe or fitting without requiring a coupling. Manufactured from malleable black iron, this fitting meets Federal Specification WW-P-521F, ANSI B-16.3 for dimensions, ANSI B-2.1 for pipe threads, and ASTM A-197 for chemical and physical properties. It is sold individually and weighs 0.41 pounds. Licensed plumbers and pipefitters install this fitting in gas, water, and industrial piping systems.

This street elbow is used in residential and commercial piping applications where a 90-degree directional change is required. The street configuration eliminates the need for an extra fitting at one end, making it useful in tight installations or when connecting directly to a valve, pump, or other threaded component. Typical applications include natural gas distribution, steam lines, and water supply piping where malleable iron fittings are specified.

Key Features

• 90-degree street elbow (1/4 bend) with one male NPT and one female NPT end
• 3/4-inch nominal pipe size with flat banded straight sizing
• Malleable black iron construction per ASTM A-197
• Dimensional compliance with ANSI B-16.3
• Pipe thread compliance with ANSI B-2.1
• Meets Federal Specification WW-P-521F

Compatibility

Designed as a standard OEM-style replacement or new-install fitting for 3/4-inch NPT malleable iron piping systems in residential and commercial applications.

Installation Notes

Installation should be performed by a licensed plumber or pipefitter in accordance with applicable local codes, IFGC, or IPC requirements. Shut off and depressurize the piping system fully before removing or installing any threaded fitting. Apply an appropriate pipe thread sealant or PTFE tape to the male threads before assembly. Do not over-torque threaded connections, as malleable iron fittings can crack under excessive force.

Technical Specifications

• Pipe Size: 3/4 inch
• Angle: 90 degrees
• Fitting Type: Street Elbow (1/4 Bend)
• Thread Type: NPT (Male x Female)
• Material: Malleable Black Iron
• Weight: 0.41 pounds
• Standards: WW-P-521F, ANSI B-16.3, ANSI B-2.1, ASTM A-197
• Sold As: Each

Standard Information

• Brand: ASC ENGINEERED SOLUTIONS
• Manufacturer Part Number: 8700127353
