Asc 390080885 Gruvlok 5 Inch Flange Seal Ring 7012

Product Description

The ASC Engineered Solutions 390080885 is a Gruvlok flange seal ring designed for use with the 7012 flange fitting in grooved piping systems. This seal ring provides a pressure-rated elastomeric seal at flanged connections, preventing leakage where grooved-style components interface with flanged piping. Sized for 5-inch pipe, it seats into the flange face to maintain a reliable, consistent seal under system operating pressures. Licensed plumbers, pipefitters, and mechanical contractors working on grooved piping installations and retrofits are the primary installers of this component.

This seal ring is intended for 5-inch grooved piping applications where the Gruvlok 7012 flange is used to transition between grooved and flanged piping systems. Typical installations include commercial and industrial HVAC hydronic systems, fire protection piping, and process piping where grooved mechanical joining is specified. It is suited for both new construction and retrofit work where flanged connections must mate with existing grooved-style infrastructure.

Key Features

• Sized for 5-inch pipe to match 7012 flange fitting dimensions
• Elastomeric construction provides a pressure-rated seal at flanged connections
• Designed for grooved-to-flanged transition points in mechanical piping systems
• OEM-style replacement seal ring for Gruvlok 7012 flange assemblies

Compatibility

Designed as a replacement seal ring for use with the Gruvlok 7012 flange on 5-inch grooved piping systems.

Installation Notes

Installation is performed by licensed plumbers or pipefitters in accordance with applicable mechanical codes and the fitting manufacturer's assembly instructions. Depressurize and drain the affected piping section completely before disassembling any flanged or grooved connection. Inspect the flange face and seating area for debris or damage before seating the new seal ring. Follow the specified bolt torque sequence for the mating flange to ensure even compression of the seal ring.

Technical Specifications

• Pipe Size: 5 inches
• Compatible Fitting: Gruvlok 7012 Flange

Standard Information

• Brand: ASC Engineered Solutions
• Manufacturer Part Number: 390080885
