Asc 390080869 Gruvlok Seal Ring 4 in 7012 7312 Flange

Product Description

The ASC Engineered Solutions 390080869 is a Gruvlok seal ring designed for use with 7012 and 7312 series grooved pipe flanges in 4-inch pipe applications. This elastomeric sealing component seats between the flange face and the mating surface, providing a pressure-rated seal at grooved piping connections. It is a direct-fit replacement element for the specified flange series and is installed by licensed plumbers, pipefitters, and mechanical contractors working on grooved piping systems in commercial and industrial settings.

This seal ring is sized for 4-inch grooved pipe and is intended for use specifically with Gruvlok 7012 and 7312 flange couplings. These flange types are common in mechanical piping systems including HVAC hydronic loops, chilled water distribution, fire protection headers, and industrial process piping where grooved-end flange connections are specified. The seal ring maintains joint integrity at the flange interface and must be replaced any time the flange joint is broken and re-made during service or system modification.

Key Features

• Sized for 4-inch grooved pipe flange connections
• Compatible with Gruvlok 7012 and 7312 flange series
• Elastomeric construction provides a positive face seal at the flange interface
• Direct replacement seal element for field service and re-assembly
• Designed for grooved mechanical piping system applications

Compatibility

Designed for use with Gruvlok 7012 and 7312 series grooved pipe flanges in 4-inch pipe size.

Installation Notes

Installation is performed by licensed pipefitters or plumbers. Depressurize and drain the piping system completely before breaking any flange joint. Inspect the flange faces and seating surfaces for damage before installing the new seal ring. Follow the flange bolt torque sequence and specifications provided by the flange manufacturer for proper joint make-up.

Technical Specifications

• Pipe Size: 4 inches
• Compatible Flange Series: 7012, 7312
• Component Type: Seal Ring

Standard Information

• Brand: ASC Engineered Solutions
• Manufacturer Part Number: 390080869
