Arzel Zoning Technology STKSS-E-8X8 EzySlide rectangular damper (8 x 8 side mount)

Product Description

Arzel Zoning Technology STKSS-E-8X8 is an 8 x 8 EzySlide rectangular zone damper for side-mount installation in rectangular duct systems. The motorless damper is designed for retrofit applications and inserts into existing ductwork. It is operated by low-pressure air supplied by Arzel control panels and features a mounting plate and actuator that can be positioned on the side or bottom depending on installation orientation.

• 8 x 8 rectangular EzySlide zone damper with side-mount configuration
• Motorless design operated by low-pressure air from Arzel control panels
• Mounting plate and actuator can be installed on side or bottom for retrofit duct applications

Product Highlights

8 x 8 motorless rectangular zone damper for retrofit rectangular duct zoning; side or bottom actuator mounting; operates on low-pressure air.

Product Information

Standard Information

• Brand: ARZEL ZONING TECHNOLOGY
• Manufacturer Part Number: STKSS-E-8X8

Technical Specifications

• Manufacturer: Arzel Zoning Technology
• Brand: Arzel
• MPN: STKSS-E-8X8
• Part Number: 564897
• Model Name: EzySlide STKSS-E
• Product Type: Zone damper
• Type: Rectangular / Square
• Size: 8 x 8 in (duct opening)
• Shape: Rectangular
• Mounting Type: Side mount (mounting plate and actuator on side)
• Mounting Options: Side or bottom (actuator can be positioned on side or bottom depending on installation orientation)
• Design: Motorless damper
• Operation: Operates on low-pressure air supplied by Arzel control panels
• Application: Retrofit applications; rectangular duct zoning
• UNSPSC: 40101504
