Arrowhead Brass 465-06QTLF Frost Free Hydrant 6 Inch Lead Free

Product Description

The ARROWHEAD BRASS PLUMBING 465-06QTLF is a frost-free yard hydrant built from red brass and rated lead free for potable water applications. It ships with a 6-inch bury depth and accepts either a 1/2-inch Female Iron Pipe (FIP) or a 3/4-inch Male Iron Pipe (MIP) connection, giving installers flexibility at the supply stub. An integrated vacuum breaker with Arrow Breaker technology delivers roughly twice the flow of standard vacuum breaker designs while producing less operating noise. The one-piece bonnet uses an O-ring seal to eliminate leak paths at the packing. Licensed plumbers and irrigation contractors install this hydrant in residential and light commercial outdoor water supply systems.

This hydrant is suited for outdoor installations where freeze protection is required. The 6-inch bury depth positions the drain valve below the frost line in many northern climate zones, automatically draining the barrel when the handle is closed to prevent ice damage. The heavy-duty metal handle is secured with stainless steel screws, resisting corrosion in exposed outdoor environments. Typical applications include residential yard service, livestock watering, landscape irrigation supply points, and light commercial exterior hose bibb replacements.

Key Features

• Frost-free design with 6-inch bury depth drains barrel automatically on shutoff
• Integrated Arrow Breaker vacuum breaker provides approximately twice the flow of standard vacuum breakers
• Lead-free red brass construction meets potable water requirements
• Dual inlet options: 1/2-inch FIP or 3/4-inch MIP for installation flexibility
• One-piece bonnet with O-ring seal eliminates packing leaks
• Heavy-duty metal handle with stainless steel screws for corrosion resistance
• Reduced operating noise compared to conventional vacuum breaker hydrants

Compatibility

Designed as an OEM-style replacement or new-installation frost-free yard hydrant compatible with 1/2-inch female iron pipe or 3/4-inch male iron pipe supply lines in residential and light commercial outdoor plumbing systems.

Installation Notes

Installation should be performed by a licensed plumber in accordance with local plumbing codes and the International Plumbing Code (IPC). Shut off the supply water and relieve pressure in the line before making any connections. The hydrant must be installed at the correct bury depth so the drain port sits below the local frost line. Do not install in a location where the drain port may become submerged, as this can defeat the vacuum breaker and create a backflow hazard.
