Armstrong International B5671 CD-3300 Series Steam Trap (1/2 x 3/4 In.) ACD3300

Product Description

Armstrong International B5671 is a CD-3300 series stainless steel disc steam trap for steam and condensate service that mounts to a 360-degree universal trap connector (less connection). It uses a three-discharge-port thermodynamic disc design and is constructed of stainless steel. Typical capacity ranges 100�800 lb/hr (up to 800 lb/hr) with an operating pressure rating to 450 psig and a high-temperature rating noted at 456 F.

• Three-discharge-port thermodynamic disc design for stable disc operation and extended service life
• All stainless steel construction; body material listed as ASTM A743 Grade CA40
• Mounts to 360-degree universal trap connector (less connection); compatible with connector strainer options

Product Highlights

CD-3300 stainless steel disc steam trap; capacity 100�800 lb/hr; operating pressure to 450 psig; mounts to 360-degree universal connector (less connection).

Product Information

Standard Information

• Brand: ARMSTRONG INTERNATIONAL
• Manufacturer Part Number: B5671

Technical Specifications

• Brand: Armstrong International
• Manufacturer Part Number (MPN): B5671
• Model: CD-3300
• Product Type: Disc steam trap (less connection)
• Replacement Part Number: ACD3300
• Material: Stainless steel
• Body Material: ASTM A743 Grade CA40 stainless steel
• Design: Three discharge port thermodynamic disc
• Connection: Less connection (connection fittings not included)
• Connection Size: 1/2 x 3/4 In.
• Mounting Type: Mounts to universal trap connector
• Compatibility: For use with 360-degree universal connector with or without strainer
• Capacity: 100�800 lb/hr (up to 800 lb/hr)
• Capacity (metric): Up to 363 kg/hr
• Operating Pressure Rating: 450 psig (31 bar)
• Temperature Rating: 456 F
• Face-to-Face Dimension: 3.5 to 4 in.
• Weight: 2.49 lb
