Armstrong Air 14V87A TSA060S4N45G Condenser Air Conditioning Unit 5 Tons 460 Volts 3 Phase

Product Description

The Armstrong Air 14V87A is a condenser air conditioning unit rated at five tons and designed for three-phase power. This unit features vertical air discharge, which allows for screening behind shrubs or storing out of sight on a roof. It is compatible with add-on indoor coils or air handlers, providing flexibility in cooling capacities. The direct drive fan ensures a high volume of air circulation through the condenser coil, enhancing the cooling process.

• Cooling capacity of sixty thousand Btu/hr
• Includes Hail Guards made of heavy-gauge steel
• Equipped with a high-pressure switch for system protection

Product Highlights

This unit is constructed from galvanized steel with a baked polyester finish for durability. It operates using R-410A refrigerant and has a scroll compressor to ensure efficient cooling. The fan motor runs at eight hundred thirty rpm, producing a flow rate of three thousand six hundred cfm.

Product Information

Standard Information

• Brand: Armstrong Air
• Part Number: L9928

Technical Specifications

• Nominal Capacity: 5 ton
• Cooling Capacity: 60000 Btu/hr
• Efficiency Rating EER: 11 EER
• Efficiency Rating SEER: 13 SEER
• Flow Rate: 3600 cfm
• Frequency: 60 Hz
• Line Size (Liquid): 3/8 in
• Line Size (Suction): 1-1/8 in
• Material: Galvanized Steel
• Motor Rating: 1/4 hp
• Motor Type: Fan
• Number of Phases: 3
• Refrigerant Type: R-410A
• Voltage: 460/575 V
• Weight: 222 lb
