Armstrong Air 1.911522 Omniguard EAC4X-50 Cased Evaporator Coil, 2 ton, 400 to 1200 cfm

Product Description

The Armstrong Air 1.911522 is a reliable cased evaporator coil designed for efficient heating and air conditioning systems. This model supports airflow between four hundred to one thousand two hundred cubic feet per minute (cfm) and is suitable for two-ton applications.

• Omniguard total corrosion protection with a proven tube and fin design.
• Factory-installed TXV for quick installation in high-efficiency applications.
• Foil-face insulation simplifies cleaning while preserving energy efficiency.

Product Highlights

This evaporator coil features a tightly sealed painted steel cabinet that ensures less than two percent air leakage. It includes a drain pan with low water retention rates to minimize odors and allergens, and it incorporates Microban technology to prevent mold growth.

Product Information

Standard Information

• Brand: Armstrong Air
• Part Number: L8503

Technical Specifications

• Air Flow Type: Upflow
• Dimensions: Twenty-three point seventy-five inches L x twenty-one point seventy-five inches W x twenty-one point sixty-two inches H
• Flow Rate: Four hundred to one thousand two hundred cfm
• Line Size (Liquid): Three-eighths inch
• Line Size (Suction): Three-quarters inch
• Metering Device: TXV
• Mfg Standards/Approvals: AHRI Certified | cULus Listed
• Nominal Capacity: Two ton
• Refrigerant Type: R-410A
• Series: EAC4X-50
• Tubing Material: Aluminum
• Type: Cased
• Warranty: Ten Years Limited Parts
