Armacell APS10043 AP ArmaFlex Insulation Sheet 1 in x 36 in x 48 in (6 per carton)

Product Description

The Armacell APS10043 AP ArmaFlex insulation sheet is a 1 inch thick closed-cell elastomeric foam sheet sized 36 in x 48 in for thermal insulation and condensation control. It has a density of 3 to 6 lb/ft3 at 73 deg F, a temperature range of -297 to 220 deg F, built-in vapor retardant and Microban antimicrobial protection, and low water absorption and vapor permeability for HVAC, refrigeration, plumbing, and industrial applications.

• Closed-cell elastomeric foam sheet, 1 in thickness; dimensions 36 in x 48 in
• Density 3 to 6 lb/ft3 at 73 deg F; temperature rating -297 to 220 deg F; R-value R4.2
• Low VOC, formaldehyde-free, built-in vapor barrier, Microban antimicrobial protection; water absorption 0.2%

Product Highlights

1 in closed-cell elastomeric sheet (36 x 48 in) for thermal insulation and condensation control; built-in vapor barrier; wide temperature range and low water absorption.

Product Information

Standard Information

• Brand: ARMACELL
• Manufacturer Part Number: APS10043
• Country of Origin: United States

Technical Specifications

• MPN: APS10043
• Brand: Armacell
• Series/Model: AP ArmaFlex
• Product Name: AP ArmaFlex Insulation Sheet
• Type: Closed-cell, flexible sheet
• Material: Elastomeric foam
• Thickness: 1 in
• Dimensions (W x L): 36 in x 48 in
• Density: 3 to 6 lb/ft3 at 73 deg F
• R-Value: R4.2
• Maximum Temperature Rating: 220 deg F
• Minimum Temperature Rating: -297 deg F
• Water Absorption: 0.2 percent
• Built-in Vapor Barrier: Yes
• Antimicrobial Protection: Microban
• Indoor Air Quality: Low VOC, fiber-free, non-particulating, formaldehyde-free
• Applications: Commercial, refrigeration, HVAC, plumbing, exposed ceiling/air plenum, schools, hospitals, mechanical systems, chillers, industrial, marine, petrochemical
• Applicable Standards/Certifications: UL 723/181/2818/94/5V-A/V-0/E55798; EPA; ASTM C534 Type 1 Grade 1; ASTM C177/C518/C209/C1763/G21/C1338/C534/E96/E84/D1056/2B1/G21/C1338/G22; CAN/ULC S102; NFPA 255/90A/90B; MEA 107-89M; MIL-P-15280J; MIL-C-3133C/MIL STD 670B; Grade SBE 3; LA-RR 76; ISO 9001
• Package Quantity: 6 sheets per carton (72 square feet per carton)
• Country of Origin: United States
• UPC: 10803014111390
