Product Description
The Arlington LPCG50 cord connector features a low-profile, liquidtight, oiltight strain relief design. With a 1/2 inch trade size, it accommodates cable openings from 0.2 to 0.472 inches. The unique grommet with gripping fingers ensures a secure fit. A sealing ring is furnished for liquidtight installation in non-threaded openings.
- Oil-tight, furnished with sealing ring and locknut
- Largest cord range in the industry
- Liquidtight seal and superior pullout resistance
Product Highlights
This low profile cord connector has a unique grommet with gripping fingers and a liquidtight seal.
Product Information
Standard Information
-
Brand: ARLINGTON
-
Manufacturer Part Number: LPCG50
-
Country of Origin: CN
Technical Specifications
-
Type: Low Profile Liquidtight Oiltight Strain Relief
-
Manufacturer: ARLINGTON
-
Cable Openings: 0.2 to 0.472 in
-
Material: Nylon/Polyethylene/Santoprene™/Zinc
-
Trade Size: 1/2 in
-
Thread Size: 1/2 Inch
-
Approval: CSA
-
Application: Liquidtight, Oiltight, Strain Relief
-
Includes: Sealing Ring, Locknut, UF Grommet and Cord Grommet
-
Cord Size: 0.200 to 0.472 Inch
-
Size: 1.042 Inch Dia x 1.792 Inch L
-
Thread Length: 0.63
-
Conductor Range: 0.2 - 0.472 Inch
-
Standards: CSA LR49636 Certified
-
Brand: ARLINGTON
-
MPN: LPCG50
-
GTIN: 00018997800862
-
UNSPSC: 39121420
-
Item Name: Low Profile Strain Relief Non-Metallic Cord Connector
-
Mounting: Threaded
-
Standard: UL, CSA
-
Insulated: No
-
Fits cable sizes: 200 - .472-inches
-
Connector Type: Threaded
-
Special Features: Oil Tight, Furnished With Sealing Ring And Locknut
-
Stripped Catalog Number: LPCG50
-
Catalog Description (MFR): Low-profile non-metallic, liquid-tight, oil-tight, and gray strain relief cord connector furnished with a sealing ring and locknut. Supports .200 to .485 cord range with a 1/2 inch trade size.
-
Invoice Description (MFR): 1/2" LOW PROFILE CORDGR
-
Safety Data Sheet (SDS) Flag: Y
-
Buy American Act (BAA) Compliant: C
-
Concatenated Invoice Description: 1/2" LOW PROFILE CORDGR
-
American Recovery and Reinvestment Act (ARRA) Compliant: C
-
UPC: 018997800862
-
Vendor SKU: LPCG50
-
Standard & Approvals: UL E105706, CSA LR49636, RoHS Complaint
-
Manufacturer Name: Arlington
-
Liquid Tight: Yes
-
Oil Tight: Yes
-
Material(s): Nylon (Body), Santoprene® (Grommet), Polyethylene (Sealing Ring), Zinc (Locknut)
