Arlington Industries FB442F L-shaped Fan and Fixture Vapor Box 70 lb Fan 200 lb Fixture

Product Description

The ARLINGTON INDUSTRIES FB442F is an L-shaped fan and fixture vapor box designed for installing fan/fixture on ceilings with 1/2" or 5/8" single drywall. It supports a 70lb fan and 200lb fixture. The flange forms a protective barrier against air infiltration and has a 2-hour fire rating. The box has a 13.4 cu-in capacity.

• Supports 70 lb fan and 200 lb fixture
• Flange forms a protective barrier against air infiltration
• 2 Hour Fire Rating

Product Highlights

The FB442F vapor box provides secure mounting and prevents air infiltration, ensuring safety and energy efficiency.

Product Information

Standard Information

• Brand: ARLINGTON INDUSTRIES
• Manufacturer Part Number: FB442F
• Country of Origin: USA

Technical Specifications

• Components: COUPLERS / JUNCTIONS
• UNSPSC Code: 39131713
• manufacturer_name: Arlington Industries
• mounting: Joist
• pdw_id: ECL1669798
• product_upc: 01899776220
• Capacity: 13.4 cu-in
• Color: Black
• Material: Plastic
• Mounting Orientation: Side
• Mounting Type: Threaded
• Shape: L-Shape
• Manufacturer: ARLINGTON INDUSTRIES
• Part Number: FB442F
• Description: Joist Mount Single Drywall
• Load Rating: UL Rated: 70lb Fan; 200lb Fixture CSA Rated: 50lb Fan; 50lb Fixture
• Usage: Protects Against Air Infiltration
• Comes With: (3) NM94 Cable Connectors (1) Mud Cover (3) Gaskets for knockouts (1) Flange Gasket (1) Box with flange (2) #12 x 2" Long Screws (1) #10 x 1" Long Screw
• ADI Part Number: 9N-FB442F
• Brand Name: Arlington Industries
• Product Name: Joist Mount Screw-On L-Shaped Vapor Box for Fans and Fixtures (Single Drywall)
• Product Type: Fixture Boxes
