Arlington DBVR141W Low Profile InBox for Retrofit Siding Construction

Product Description

The Arlington DBVR141W is a low profile InBox designed for retrofit siding construction. This recessed electrical box has a one-piece design, making installation easy and reducing the visible footprint on the exterior. It is made from UV-rated plastic, ensuring durability in outdoor applications. The dimensions are seven point one eight six inches in length, four point nine three four inches in width, and five point one six inches in depth.

• One-piece low profile assembly for easy installation
• Accepts standard single gang wiring devices
• Weatherproof cover maintains protection for outdoor use

Product Highlights

This InBox replaces the need for an electrical box, siding block, and bubble cover, streamlining installation. It is ideal for applications requiring a clean look in retrofit siding projects.

Product Information

Standard Information

• Manufacturer: Arlington
• Part Number: DBVR141W

Technical Specifications

• Capacity: 22 cu-in
• Enclosure Type: NEMA 3R
• Mounting Orientation: Vertical
• Material: UV-Rated Plastic
• Color: White
• Dimensions: 7.186 in x 4.934 in x 5.16 in
• Number of Gangs: 1
• Number of Outlets: 1
