Arlington CPS50 Concrete Pipe Sleeve 5 Inch

Product Description

The ARLINGTON CPS50 is a concrete pipe sleeve designed to create a clean, formed opening through concrete floor pours for cable and conduit runs between floors. Installed before the concrete is poured, this sleeve holds its shape during the pour and leaves a finished, code-appropriate penetration once the concrete sets. It provides a reliable, economical method for electricians and low-voltage installers to route conduit or cable bundles vertically through structural concrete slabs without coring after the fact. The CPS50 produces a 5-inch hole, making it well suited for multi-circuit conduit runs or larger cable assemblies in commercial and residential construction.

This sleeve is intended for use in poured concrete floor applications on new construction projects where conduit or cable must transition from one floor level to the next. Electrical contractors and general contractors working on multi-story residential and commercial structures commonly install these sleeves during the formwork and pre-pour stage. The 5-inch opening accommodates a range of conduit sizes and multi-cable configurations in a single penetration, reducing the number of separate sleeves required per floor location.

Key Features

• Creates a 5-inch finished opening through poured concrete floors for conduit or cable passage
• Installed prior to concrete pour, eliminating the need for core drilling after the slab sets
• Economical sleeving method suited for both residential and commercial multi-story construction
• Accommodates a variety of conduit types and cable bundles in a single penetration
• Allows cables or conduit to run cleanly from one floor to the next with a formed, consistent opening

Compatibility

Designed as an OEM-style pre-pour concrete sleeve for use in poured concrete floor slab applications where a 5-inch conduit or cable penetration is required.

Installation Notes

Installation is performed by the electrical contractor or general contractor during the pre-pour stage, before concrete is placed. The sleeve should be secured in position within the formwork to prevent movement during the pour. Follow applicable NEC requirements for conduit fill, sleeve sealing, and firestopping at floor penetrations after conduit is installed. Once the slab has cured, any required firestop material should be applied around conduit or cables passing through the sleeve per local code.

Technical Specifications

• Hole Size: 5 inches
• UPC: 018997721549

Standard Information

• Brand: ARLINGTON
• Manufacturer Part Number: CPS50
