Arlington 8416 2-1/2 Mc Cable Connector With End Stops

Product Description

The Arlington 8416 is a die-cast zinc MC feeder cable connector designed for use with steel and aluminum cables. It is engineered to secure into a two-and-a-half-inch knockout using a steel locknut. The connector includes an end stop and additional end stop bushings, making it adaptable for various cable sizes ranging from two point one to two point seven inches in diameter. This product ensures a tight fit when taped, thereby enhancing durability and safety.

• Built-in end stop for added convenience
• Concrete tight when taped
• Compatible with various cable sizes

Product Highlights

The Arlington 8416 is ideal for electrical applications where secure and reliable connections are essential. It provides a robust solution for flexible metal conduit systems.

Product Information

Standard Information

• Manufacturer: Arlington
• Part Number: 8416

Technical Specifications

• Trade Size: 2-1/2 inches
• Material: Die Cast Zinc
• Dimensions: 3.218 inches L x 3.235 inches W x 4.25 inches H
• Connection Type: MNPT
• Cable Openings: 2.1 to 2.7 inches
• Knockout Size: 2-1/2 inches
• Weight: 1.25 pounds
• Country of Origin: United States
