Arc Abrasives 904163803 Type 1 Cut Off Wheel 4in Box of 50

Product Description

The ARC ABRASIVES 904163803 is a Type 1 flat cut off wheel designed for fast, clean cutting across all metals. Built under the Predator line, this wheel measures 4 inches in diameter by 1/16 inches thick with a 3/8-inch arbor bore. It carries an A46T abrasive grade, balancing aggressive material removal with extended wheel life. Rated at 19,100 RPM, it is suited for use on standard angle grinders and cut off tools common in trade and fabrication environments. Each box contains 50 wheels. The self-sharpening abrasive formulation maintains a consistent cut edge throughout the wheel's life, reducing glazing and heat buildup at the cut zone.

This cut off wheel is a practical choice for metal fabrication shops, mechanical contractors, plumbers, and electricians who regularly cut ferrous and non-ferrous metals on the job. Its thin 1/16-inch kerf minimizes material loss and reduces the effort needed to complete each cut. The wheel is appropriate for use on pipe, conduit, angle iron, sheet metal, and similar materials. The 50-count box format suits service vehicles and shop storage where consistent supply is needed across multiple technicians or job sites.

Key Features

• Type 1 flat profile for straight cut off applications
• A46T abrasive grade rated for use on all metals
• 19,100 RPM maximum operating speed
• 1/16-inch kerf thickness reduces heat and material waste
• Self-sharpening construction maintains cut performance throughout wheel life
• 50 wheels per box for high-volume use

Compatibility

Designed for use on standard angle grinders and cut off tools accepting a 3/8-inch arbor bore and rated for Type 1 wheels at or above 19,100 RPM.

Installation Notes

Installation and use of abrasive cut off wheels must follow ANSI B7.1 safety standards. Always verify that the grinder or cut off tool is rated at or above the wheel's maximum RPM before mounting. Power down and disconnect the tool before changing wheels. Wear appropriate PPE including eye protection, gloves, and hearing protection during operation.

Technical Specifications

• Wheel Type: Type 1 (Flat)
• Diameter: 4 inches
• Thickness: 1/16 inches
• Arbor Bore: 3/8 inches
• Abrasive Grade: A46T
• Maximum RPM: 19,100
• Box Quantity: 50 wheels
• Package Weight: 3.4 pounds

Standard Information

• Brand: ARC ABRASIVES
• Manufacturer Part Number: 904163803
