Aquatherm 1030250933 3 x 1 x 1 Fpt Aquatherm Green Fusion

Product Description

The AQUATHERM 1030250933 is a weld-in saddle fusion outlet with a nominal size of 8 - 10 X 1 X 1 IN. Constructed from Fusiolen PP-R, it conforms to material standard ASTM F2389 and industry standards DIN 16962 and DIN EN ISO 15874. It features a socket weld X brass FNPT connection type and an outside diameter of 60 MM.

• Weld-In Saddle Fusion Outlet
• Socket Weld X Brass FNPT Connection
• Includes hex-shaped female thread, weld-in surface and weld-in socket for fusion with the inner wall of the pipe

Product Highlights

This fusion outlet is designed for creating connections in PP-R and PP-RCT piping systems, ensuring a strong, reliable joint.

Product Information

Standard Information

• Brand: AQUATHERM
• Manufacturer Part Number: 1030250933

Technical Specifications

• Nominal Size: 8 - 10 X 1 X 1 IN
• Connection Type: Socket Weld X Brass FNPT
• Outside Diameter: 60 MM
• Material: Fusiolen® PP-R
• Material Standard: ASTM F2389
• Industry Standards: DIN 16962, DIN EN ISO 15874
• Other Physical Dimension: 43 MM Saddle End, 25.4 X 39 MM Thread End, 200 MM Saddle Diameter, 43 MM Center To End
• Item Name: Weld-In Saddle Fusion Outlet
