Honeywell L6006A1145 Immersion Control

Product Description

The Honeywell L6006A1145 Immersion Control is designed for HVAC systems to regulate and limit the temperature of liquids in boilers, storage tanks, and other applications. This control features a 100 - 240 degrees Fahrenheit operating range with an adjustable 5 - 30 degrees Fahrenheit differential.

• Micro Switch snap-acting switches
• Visible control point scale
• Horizontal or vertical insertion

Product Highlights

This immersion control is suitable for use in both residential and commercial HVAC systems, ensuring precise temperature control and efficient operation.

Product Information

Standard Information

• Brand: Honeywell
• MPN: L6006A1145

Technical Specifications

• Temperature Range: 100 - 240 degrees Fahrenheit
• Differential: 5 - 30 degrees Fahrenheit, adjustable
• Switch Type: SPDT
• Bulb Size: 3/8 x 2-7/8 inches copper
• Capillary Length: 3 inches
• Insulation Depth: 3 inches
• Mounting Type: Horizontal
• Dimensions: 5-5/8 inches H x 2 inches W x 2-1/8 inches D
