Aqualine EL90-075-CMIPT Cast Brass Street 90 Elbow 3/4 in

Product Description

The AQUALINE EL90-075-CMIPT is a cast brass street 90-degree elbow fitting in a 3/4 inch SxT configuration. This fitting connects a sweat (solder) end directly to a threaded female connection, allowing a 90-degree change in direction without requiring a separate coupling or union. Cast brass construction provides reliable corrosion resistance for use in potable water, hydronic, and general plumbing applications. Plumbers and pipefitters install this type of fitting during rough-in and retrofit work where space is limited and a low-profile directional change is needed.

This street elbow is suited for residential and light commercial plumbing systems where copper tubing transitions to a threaded connection at a 90-degree angle. The SxT end configuration means one end accepts standard copper tube by soldering while the other end connects to a female NPT threaded fitting or valve. It is a commonly specified component in water supply lines, boiler piping, and hydronic heating systems.

Key Features

• Cast brass construction for durability and corrosion resistance in wet plumbing environments
• 90-degree street elbow geometry eliminates the need for an additional coupling at direction changes
• SxT end configuration: sweat (solder) inlet by female NPT threaded outlet
• 3/4 inch nominal size suits standard residential and light commercial water supply applications
• Order increment of 1 allows single-unit purchasing

Compatibility

Designed as an OEM-style replacement and general-use fitting for 3/4 inch copper tube plumbing systems requiring a sweat-to-female-thread 90-degree transition.

Installation Notes

Installation should be performed by a licensed plumber in accordance with applicable local plumbing codes and the International Plumbing Code (IPC). Shut off water supply and fully depressurize and drain the line before soldering or making any threaded connections. Use appropriate flux and solder rated for potable water on the sweat end, and apply thread sealant or PTFE tape to the threaded end per local code requirements. Do not over-tighten threaded connections on cast brass fittings.

Technical Specifications

• Size: 3/4 inch
• End Configuration: SxT (Sweat by Female NPT Thread)
• Fitting Angle: 90 degrees
• Fitting Type: Street Elbow
• Material: Cast Brass
• Weight: 0.21 pounds

Standard Information

• Brand: AQUALINE
• Manufacturer Part Number: EL90-075-CMIPT
