Appleton SVL524100 Conduit Body

Product Description

The APPLETON SVL524100 is a conduit body designed for use in electrical raceway systems. Conduit bodies serve as access points within a conduit run, allowing wire pulling, splicing, and directional changes in an electrical installation. The SVL524100 weighs 1.46 pounds and is built to APPLETON's heavy-duty specifications. Licensed electricians and electrical contractors install this fitting as part of a complete conduit assembly in commercial, industrial, and residential wiring systems.

This conduit body is suited for use in electrical conduit systems where access to conductors is required for pulling, inspection, or splicing. It is appropriate for installations governed by the National Electrical Code (NEC) and is a standard component in industrial and commercial electrical raceways. Its heavy-duty designation indicates suitability for demanding service environments.

Key Features

• Heavy-duty construction rated for demanding electrical raceway applications
• Provides conductor access for wire pulling, splicing, and directional changes
• Weighs 1.46 pounds for a solid, durable build
• Compatible with standard conduit raceway systems per NEC requirements

Compatibility

Designed as an OEM-style replacement or new-installation conduit body for use in standard electrical conduit raceway systems.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and all applicable local codes. De-energize and lock out the circuit before opening or servicing any conduit body. Ensure the conduit body is properly secured and all covers are tightened to maintain the integrity of the raceway system. Do not exceed the conductor fill capacity specified for the conduit body size.

Technical Specifications

• Weight: 1.46 pounds
• UPC: 78347287323

Standard Information

• Brand: APPLETON
• Manufacturer Part Number: SVL524100
