Appleton STN-125 1-1/4 inches Straight Insulated Liquidtight Connector

Product Description

The APPLETON STN-125 is a 1-1/4" straight insulated liquidtight connector. It terminates liquidtight flexible metal conduit (LFMC) and liquidtight flexible nonmetallic conduit (LFNC) into an enclosure or junction box. Constructed from malleable iron with a triple-coat finish for corrosion protection in demanding industrial environments.

• Insulated throat protects conductor insulation
• Triple-coat finish provides layered corrosion protection
• Rated concretetight, oiltight, and raintight per ul 514b

Product Highlights

This liquidtight connector is suitable for use with liquidtight flexible metal conduit in sheet metal enclosure installations.

Product Information

Standard Information

• Brand: APPLETON
• Manufacturer Part Number: STN-125
• Country of Origin: United States

Technical Specifications

• Material: Malleable Iron
• Diameter: 1 1/4 in
• MPN: STN-125
• Brand: Appleton
• Country of Origin: United States
• Component: Connector
• Conduit Type: LFMC / LFNC
• Connection Orientation: Straight
• Enclosure Rating: Concretetight / Oiltight / Raintight
• Enclosure Rating Specs: UL 514B
• Finish: Triple Coated
• Fitting Type: Connector
• Hazard Rating Specs: Class I, Division 2
• Insulated: Yes
• Specifications Met: UL 514B, Class I, Div 2, CSA 065178, CSA C22.2 No. 18.3, UL File No. E14814
• Trade Size: 1-1/4"
• Brand Name: Appleton
• Brand Part Number: STN-125
• UPC: 781381684903
