Appleton SDP2-12-100T Din Rail Power Supply 12V

Product Description

The APPLETON SDP2-12-100T is a DIN rail-mounted power supply designed for industrial and commercial control panel applications. It converts standard AC line voltage to regulated 12-volt DC output, providing stable power to control circuits, sensors, and automation components. The unit mounts directly to standard DIN rail, making it a clean, space-efficient solution for panel builders and licensed electricians assembling control enclosures. With a 100-watt output capacity, it handles demanding loads across a range of industrial environments. Its compact form factor supports efficient panel layouts without sacrificing output capacity.

This power supply is suited for use in industrial control panels, building automation systems, and commercial electrical enclosures where regulated 12-volt DC power is required. It is appropriate for both new construction and retrofit panel builds. Electricians and panel integrators working on factory automation, process control, or building management systems will find this unit a straightforward fit for DIN rail assemblies.

Key Features

• DIN rail mounting for fast, tool-minimal installation in standard control enclosures
• 12-volt DC regulated output for control circuit and sensor applications
• 100-watt output capacity supports multiple simultaneous loads
• Compact dimensions (4.9 x 5.7 x 2.7 inches) conserve panel space
• Lightweight at 0.5 pounds for easy panel handling and transport

Compatibility

Designed as an OEM-style replacement or new-install power supply for standard DIN rail control panels requiring 12-volt DC regulated output at up to 100 watts.

Installation Notes

Installation should be performed by a licensed electrician in accordance with NEC requirements for control panel wiring and power supply mounting. Disconnect and lock out all AC power to the enclosure before installing or replacing this unit. Secure the unit firmly to a standard 35mm DIN rail before making any wiring connections. Verify load current requirements do not exceed the rated output capacity before energizing the panel.

Technical Specifications

• Output Voltage: 12 volts DC
• Output Power: 100 watts
• Mounting Type: DIN Rail
• Dimensions (L x W x H): 4.9 x 5.7 x 2.7 inches
• Weight: 0.5 pounds
• UPC: 78347215165

Standard Information

• Brand: APPLETON
• Manufacturer Part Number: SDP2-12-100T
