Appleton SBL-3-Q SEL.SWITCH LOCKING-BRKT

Product Description

The Appleton SBL-3-Q is a selector switch locking device designed for safe operations in hazardous environments. This product is essential for controlling motors in areas where explosive vapors or gases may exist. The SBL-3-Q design ensures secure locking in two or three positions, allowing for flexibility in control applications.

• Explosionproof and dust-ignitionproof construction
• Ideal for use in chemical plants and refineries
• Factory sealed design eliminates the need for additional sealing fittings

Product Highlights

This locking bracket provides a reliable means to prevent unauthorized operation of connected motors and equipment. It conforms to safety standards for operation in classified locations.

Product Information

Standard Information

• Type: Selector Switch Locking Device
• Brand: Appleton

Technical Specifications

• Catalog Number: SBL-3-Q
• Manufacturer: Appleton Electric
• Country of Origin: Mexico
• Locking Positions: Two or Three
• Construction Feature: Explosionproof, Dust Ignitionproof
• Enclosure Rating: Class I Div 1 and 2, Class II Div 1 and 2, Class III, NEMA 3R/7B/7C/7D/9E/9F/9G
• UPC: 781381257527
• GTIN: 00781381257527
