Appleton RN-75 Offset Conduit Nipple 0.75 Inch

Product Description

The APPLETON RN-75 is a 0.75-inch trade size offset conduit nipple used to make minor directional transitions in rigid metal conduit runs. The offset design allows a conduit system to shift slightly in plane without the need for a full elbow or a separate offset fitting, keeping the run compact and reducing the number of components. Electricians use this fitting in commercial and industrial installations where conduit must clear a structural obstruction or align with a knockout that is not perfectly in line with the conduit path. The RN-75 is a compact, low-profile piece that installs quickly with standard threading tools.

This fitting is suited for use in rigid metal conduit and intermediate metal conduit systems in commercial, industrial, and utility applications. It is commonly installed at panel knockouts, junction boxes, and equipment enclosures where minor lateral offset is needed to achieve clean conduit entry alignment. The fitting is appropriate for indoor and outdoor installations depending on the enclosure or conduit system it is paired with.

Key Features

• 0.75-inch trade size offset design for minor conduit alignment corrections
• Compact form factor minimizes space requirements in tight conduit runs
• Threaded ends for secure connection to rigid or IMC conduit
• Lightweight construction at 0.1 pounds per fitting

Compatibility

Designed as an OEM-style fitting for 0.75-inch trade size rigid metal conduit and intermediate metal conduit systems in commercial and industrial electrical installations.

Installation Notes

Installation is performed by licensed electricians in accordance with NEC requirements for conduit wiring methods. De-energize all circuits in the affected conduit run before beginning work. Use appropriate threading dies and conduit wrenches to make up threaded connections; apply listed thread compound or tape as required by the installation environment. Verify that the offset geometry clears obstructions before tightening final connections.

Technical Specifications

• Trade Size: 0.75 inches
• Package Length: 5 inches
• Package Width: 4 inches
• Package Height: 0.6 inches
• Weight: 0.1 pounds
• UPC: 68785529075

Standard Information

• Brand: APPLETON
• Manufacturer Part Number: RN-75
