Appleton LR27 Type LR Conduit Outlet Body, 3/4 in Hub, Form 7, 6.9 cu-in Capacity

Product Description

The Appleton LR27 is a type LR conduit outlet body designed for use in rigid conduit applications. This model features a three-quarter inch hub and has a capacity of six point nine cubic inches. Made from Grayloy iron, it ensures durability for electrical installations. The item is suitable for wet locations when paired with the right covers.

• Designed with a flat back for better wire capacity and surface mounting.
• Interchangeable with other manufacturers' Form 7 conduit bodies.
• Time-efficient clip-on covers support easy installation.

Product Highlights

The Appleton LR27 is ideal for electrical installations requiring reliability and adaptability. Its clearly marked internal volume and maximum wire capacity make it a practical choice for professionals.

Product Information

Standard Information

• Brand: Appleton
• MPN: LR27

Technical Specifications

• Application: Rigid/IMC Conduit Applications
• Capacity: 6.9 cu-in
• Color: Gray
• Connection Type: Tapered FNPT
• Country of Origin: MX
• Dimensions: Five and three-sixteenths in L x two and seven-sixteenths in W x one and five-eighths in H
• Enclosure: NEMA FB-1/FB-2.10
• Finish: Aluminum Enamel/Zinc Electroplated
• Form: Form 7
• Hub Size: 3/4 in
• Material: Grayloy Iron
• Mfg Standards/Approvals: RoHS Compliant, UL 514A, C22.2, Federal Specification A-A-50563
• Mounting Type: Surface
• Number of Hubs: 2
• Package Weight: 1.3 lb
• Warranty: Limited
