Product Description
The Appleton LR125-M is a 1-1/4 inch LR-Type conduit body, constructed from malleable iron. This product features a length of eight point one nine inches and a width of three and a half inches. The triple-coat finish, including zinc electroplate, chromate, and epoxy powder coating, enhances its durability. It includes a tapered female threaded connection for secure fittings, and is designed specifically for junction applications involving rigid steel or aluminum conduit and IMC.
- Hub Size: 1-1/4 inch
- Form Type: 35
- Material: Malleable Iron
Product Highlights
This conduit body serves multiple functions including connecting and changing direction of conduit runs, and providing access to conductors for maintenance.
Product Information
Standard Information
-
Manufacturer: Appleton Electric
-
UPC: 78138148190
Technical Specifications
-
Hub Size: 1-1/4 inch
-
Length: eight point one nine inches
-
Width: three and a half inches
-
Material: Malleable Iron
-
Connection: Tapered Female Threaded
-
Finish: Triple-Coat (Zinc Electroplate, Chromate, Epoxy Powder Coat)
-
Form Type: 35
-
Special Features: Provides access for maintenance; allows compact connections; supports changes in conduit direction.
