Product Description
The Appleton LR100-M is a type LR conduit outlet body made from malleable iron. This conduit body is designed for use with rigid steel and aluminum conduit and IMC. It features a hub size of one inch and a form type of 35. The length is six and one-fourth inches, and the width is two point five six inches. The finish includes a triple-coat of zinc electroplate, chromate, and epoxy powder coat for enhanced durability.
- Hub Size: One Inch
- Length: Six and One-Fourth Inches
- Material: Malleable Iron
Product Highlights
This product serves numerous applications like providing openings for splicing, connecting and changing the direction of conduit runs, and allowing access to conductors for maintenance.
Product Information
Standard Information
-
Catalog Number: LR100-M
-
Manufacturer: Appleton Electric
Technical Specifications
-
Form Type: 35
-
Material: Malleable Iron
-
Finish: Triple-Coat (Zinc Electroplate, Chromate, and Epoxy Powder Coat)
-
Application: For Use with Rigid Steel, Rigid Aluminum Conduit, and IMC
-
Connection: Tapered Female Threaded
-
Hub Location: 90 Degree
-
Number of Hubs: 2
-
UPC: 78138148175
