Appleton IBC-350L-20AC Bushings, GIB-LS Series 3-1/2 IN

Product Description

The APPLETON IBC-350L-20AC insulated grounding bushing with aluminum lay-in-lug fastens and grounds threadless rigid metal conduit to an enclosure. It features a self-extinguishing insulating liner and is UL listed for use with copper or aluminum grounding conductors. The GIB-LS series includes a set screw for locking the bushing in the desired position.

• UL listed for use with copper or aluminum grounding conductors
• GIB LS Series is provided with a set screw allowing fitting to lock bushing in any desired position
• Insulating liner material is self extinguishing

Product Highlights

Insulated grounding bushing with aluminum lay-in-lug, suitable for use with copper or aluminum grounding conductors.

Product Information

Standard Information

• Brand: APPLETON
• Manufacturer Part Number: IBC-350L-20AC

Technical Specifications

• Manufacturer Part Number: GIB-350L-20AC
• Manufacturer: Appleton
• Product Series: GIB-LS
• Family Series: Appleton Bushings, GIB-LS Series
• Description: Insulated Grounding Bushing With Aluminum Lay-In-Lug, Size: 3-1/2 IN, Material: Malleable Iron, Finish: Zinc Electroplated Body, Tin Plated Lug, Connection: Threaded, Temperature Rating: 150 DEG C, Dimensions: 1 IN Height X 4.5 IN Diameter, Cable Size:
• Grounding: Yes
• Hazardous Location: No
• Temperature Rating: 150 °C
• Insulation Material: Plastic
• Mounting: Set Screw
• Composition: Iron
• Trade Size: 3.5 "
• Conduit Fitting: RMC (Rigid Metallic Conduit), IMC (Intermediate Metallic Conduit)
• Approvals: CSA, UL
• Comments: Listed for Ordinary Locations
• Net Weight: 0 lbs
• Gross Weight: 0.64 lbs
